Pixelhue Go 4K Video Processor & Switcher

CALL

Description

Pixelhue GO-4K (part of the larger GO series) is a high-performance video processor and switcher designed for real-time 4K signal management. It utilizes a robust FPGA system architecture to achieve ultra-low latency, typically just 1 frame.

Key Description

The GO-4K is engineered for high-end rental, stage control, and broadcasting environments. It specializes in:

  • Real 4K Processing: Support for full 4K×2K@60Hz resolution across inputs and outputs.
  • Versatile Conversion: Acts as a seamless switcher, scaler, and signal converter.
  • Superior Image Quality: Features high-performance scaling cores with 4:4:4 10-bit internal video processing.
Technical Specifications
Feature Specification
Max Resolution4096×2160 @ 60Hz (Real 4K)
Internal Processing4:4:4 10-bit
Latency1 frame
LayersSupports up to 3x 4K layers for mixing media server content, live cameras, and presentations
ControlFront panel with TFT screen and rotary knob; web browser control via Ethernet
ProtectionHDCP 2.2 (HDMI) and HDCP 1.3 (DP) compliant
Connectivity
  • Inputs: Includes HDMI 2.0DP 1.2, dual 12G-SDI, and dual DVI.
  • Outputs: Features HDMI 2.0DP 1.212G-SDIDVI, and HDBaseT (supports up to 100 meters via CATx).
  • Loop-through: Re-driven 12G-SDI loop outputs for signal daisy-chaining.
Physical & Electrical
  • Dimensions: Approximately 482.6 mm x 295.6 mm x 50.5 mm.
  • Weight: 4.7 kg.
  • Power: 100–240 VAC, 55W average consumption.
  • Operating Temp: 0°C to 50°C.
