Technics SL-1210 MK7

Rp28.350.000

SKU: TCNC-SL1210-MK7 Categories: , , Tags: , ,

Description

Diverse New Functions Adapt to Your Playing Style

Torque and Brake Speed Adjustment
Our latest digital motor control technology, developed from Blu-ray disc products, lets you adjust the torque and brake speed separately in four steps for precise control.

Pitch Control Function

Fine-tune your rotation speed within ±8% / ±16% with our digital pitch control function. It uses digital control from slider position detection to motor rotation, eliminating unnecessary DA conversion. This ensures accurate and stable pitch adjustments for improved tracking performance.

Reverse Play Function

Explore new creative possibilities with the reverse play function, making its debut in the SL-1200 Series. You can switch between 33-1/3 rpm, 45 rpm, and even 78 rpm speeds.

Coreless Direct Drive Motor for Stable Rotation

The direct drive system uses a slow-turning motor to directly drive the platter, offering high performance, accuracy, and powerful torque without needing part replacements. While traditional direct drive systems had issues with rotation irregularity (cogging), the SL-1200MK7 features a new coreless direct drive motor that eliminates this problem. The motor’s improved magnetic force and optimized gap between the stator and rotor ensure smooth rotation and high torque, matching the SL-1200MK5. This results in accurate and faithful sound reproduction from your records.

High Sensitivity Tonearm for Reliable Performance

The tonearm, a favorite in the DJ scene for years, features the trusted static-balance universal S-shape design. With high-precision bearings, it offers better initial-motion sensitivity than the SL-1200MK6. This means it accurately tracks the record grooves, ensuring excellent performance and minimal stylus jumping, even during intense scratching sessions.

High-rigidity Cabinet and High-damping Insulator

Our advanced chassis design, inspired by high-end turntables, reduces external vibrations for pristine audio quality. The aluminium die-cast chassis, combined with ABS and glass fibre, creates a robust two-layer construction that enhances vibration-damping.

High-rigidity Cabinet and High-damping Insulator

Detachable and Gold-Plated Terminals for Flexibility and Connectivity
The power and phono cable terminals are detachable, making maintenance and transportation easier. The gold-plated phono terminals minimize sound quality degradation by preventing corrosion and oxidation, ensuring a stable and high-quality connection. This design allows for easy cable replacement and upgrades, keeping your system in optimal condition.



Turntable section

  • Type

    • Direct Drive Manual Turntable
  • Turntable Speeds

    • 33-1/3, 45 rpm (with switch 78 rpm)
  • Starting Torque

    • 0.18 N・m / 1.8 kg・cm
  • Build-up Characteristics

    • 0.7 s. from standstill to 33 1/3 rpm
  • Wow And Flutter

    • 0.025 % W.R.M.S.
  • Turntable Platter

    • Aluminium diecast
      Diameter : 332 mm
      Weight : Approx. 1.8 kg (Including slipmat and slipsheet)

Tonearm Section

  • Type

    • Universal Static Balance
  • Effective Length

    • 230 mm
  • Overhang

    • 15 mm
  • Tracking Error Angle

    • Within 2° 32′ (at the outer groove of 30 cm record)
      Within 0° 32′ (at the inner groove of 30 cm record)
  • Offset Angle

    • 22°
  • Arm-height Adjustment Range

    • 0 – 6 mm
  • Stylus Pressure Adjustment Range

    • 0 – 4 g (Direct Reading)
  • Head Shell Weight

    • Approx. 7.6 g
  • Applicable Cartridge Weight Range

    • (without auxiliary weight)
      5.6 – 12.0 g
      14.3 – 20.7 g (including head shell)
  • Head Shell Terminal Lug

    • 1.2 mmφ 4-pin terminal lug

Terminals

  • Audio Output

    • PHONO (Pin Jack) x 1, EARTH TERMINAL x 1

General

  • Power Supply

    • AC 110 – 240 V, 50 / 60 Hz
  • Power Consumption

    • 8 W
      Approx. 0.2 W (Standby)
  • Dimensions (W x H x D)

    • 453 x 169 x 353 mm
  • Weight

    • Approx. 9.6 kg
  • Accessories

    • Turntable, Slipmat, Slipsheet, Dust cover, EP record adaptor, Balance weight, Head shell, Screw set for cartridge, PHONO cable, PHONO earth lead, AC power supply cord, Owner’s Manual
